Overcoming Intraoperative Patient Movement With Intellijoint HIP®

Written by Lee Preiss

In the last few years of total hip arthroplasty, acetabular component orientation has become one of the most controversial topics. Safe zones for cup position were created to help guide surgeons in reducing complications such as dislocation. Overcoming intraoperative patient movement is key to maintaining these safe zones.

Lewinnek’s now infamous paper from 19781 which set the first guideline was revisited by Callanan’s group in 20112 and both have fallen from a gold standard paper & Charnley award-winning pedestal to being viewed as almost medical malpractice in recent publications.3,4

Inclination Anteversion
Lewinnek et al. 19781 40° +/- 10° 15° +/- 10°
Callanan et al. 20112 40° + 5°/- 10° 15° +/- 10°

These ‘safe zones’ can still offer some boundaries to work within and perhaps now indicate a ‘tread with caution’ approach to being outside of them.

A chart comparing inclination and anteversion as it relates to patient movement.

Problem of consistency

Whether surgeons choose this framework or something more tailored to a single patient’s anatomy, we still need to consider the problem of consistently hitting the surgeon’s preferred component orientation. So we can at least leverage the fact these ‘safe zones’ are widely published to help illustrate the problem of consistency.

A quick literature review can show that Lewinnek’s zone is missed between 20 – 30% of the time5,6 and Callanan’s between 38 – 62% of the time.2,6,7 With target ranges of 20° and still a reasonably high chance of missing, what happens to our accuracy and precision as we move to this new paradigm of targets where a consistent 40° / 20° is desired or a variable, functional target derived from a hip-spine work up?

I think the answer is obvious – that both accuracy & precision will decrease – but why?

Decrease in accuracy and precision

Dr. Peter Sculco, a leading hip and knee replacement surgeon at the Hospital for Special Surgery helped outline a few reasons for this including the inability to see internal landmarks due to

  • Smaller incisions,
  • Exposure issues, and
  • High BMI patients

He also noted that even when you can see these landmarks, that they may have a unique acetabular morphology including:

  • Lack visibility of the transverse acetabular ligament, and
  • Osteophytes covering the true acetabulum.

In addition to these internal landmark difficulties, external landmarks can be affected by intraoperative patient movement.

Intraoperative patient movement

Intraoperative patient movement is a well-documented, common occurrence in total hip arthroplasty and perhaps a significant contributor to the lack of consistent component orientation in literature.8-11

So what is it?

Intraoperative patient movement can be broken into two major components:

  1. Patient Roll
    • Rotation of the body and pelvis in the transverse plane of the patient – ie. the patient rolling towards prone or supine
  2. Patient Pitch / Obliquity
    • Rotation of the pelvis in the coronal plane of the patient – ie. the movement of the inter-ASIS or interischial line away from vertical
A diagram of patient laying on a bed to show the degrees and direction of movement.

Intellijoint HIP® has the ability to track these movements due to our camera being fixed to the patient’s pelvis. Between our research and previously published data we know that:

  • 1 in 4 patients roll greater than 10°8 with an average roll of 14.5°11 and,
  • 1 in 5 patients pitch greater than 4°8
  • These values are independent of surgeon, BMI, sex & pre-op ROM10

These numbers show a high rate of occurrence for substantial movement. But how does this translate into component orientation?

The relationship was determined through simulation that 1° of Roll equates to 0.64° of Anteversion and -0.20° of Inclination and that 1° of Pitch equates to 1° of Inclination.12 It’s also important to note that there is a bias to the direction of this movement in a lateral decubitus positioned patient – in roll it’s anteriorly and in pitch, it’s towards the head.10

So in simpler terms – that average roll of 14.5° becomes 9.3° of underestimated Anteversion and 2.9° of overestimated Inclination and a 40° / 20° quickly becomes a 43° / 11° and a surprise on the post-op.

Xray pictures of hip replacement joints to show differences in inclination and anteversion.

Intellijoint HIP® makes it easy to assess patient movement via a Patient Tilt Monitor built into the software and account for it throughout a case so you don’t get caught off guard in a case like this. Our Universal V-Block can attach to any acetabular inserter and provide real-time quantitative data with any patient movement accounted for by the navigation system.

An illustration showing Intellijoint HIP being used to overcome patient tilt.

This makes our open-platform, easy-to-use, computer-assisted navigation system uniquely poised to provide a more consistent acetabular orientation by removing known barriers to missing your target preference.
